High Precision Dual Axis Slewing Drive Gearbox For Heliostat Tower CSP

High Precision Dual Axis Slewing Drive Gearbox For Heliostat Tower CSP

  • High Precision Dual Axis Slewing Drive Gearbox For Heliostat Tower CSP
  • High Precision Dual Axis Slewing Drive Gearbox For Heliostat Tower CSP
High Precision Dual Axis Slewing Drive Gearbox For Heliostat Tower CSP
Product Details:
Place of Origin: China
Brand Name: HangTuo
Certification: CE, ISO9001
Model Number: SDE3"
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 100~1600/ pc
Packaging Details: plywood box
Delivery Time: 15~45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 pcs per month
Contact Now
Detailed Product Description
Brand Name: Hangtuo Material: QT
OEM: Yes Certificate: ISO9001, CE
Package: Plywood Case Matched Motor: Electrical Motor
Color: As Requirement Precision: ≤0.1°
High Light:

High Precision Slewing Drive Gearbox

,

Electrical Motor Slewing Drive Gearbox

,

Heliostat Slewing Drive Gearbox

High Precision Dual Axis Slewing Drive Gearbox For Heliostat Or Tower CSP



Dual Axis Slewing Drive Description



Welcome to purchase the high quality and functional dual axis slewing drive worm gear for sun tracking system from our company, one of the leading and professional manufacturers and suppliers in China.



The slewing drive is an upgraded product of the slewing bearing, which usually consists of a worm, a turbine slewing bearing, a casing, and a power source. The shell is made of high-quality cast steel with very high strength. The worm gear and worm are made of ductile iron, and the wear resistance and strength are higher than the traditional gas nitriding 50Mn material in China. Compared with other domestic enveloping toroidal worms, the hardness is stronger. Longer service life. This product can be used for flatbed transport vehicles, log cranes, single-column cranes, beam lifters, truck-mounted cranes, aerial work vehicles, solar energy for solar inspections, automation equipment and other mechanical equipment; in the solar photovoltaic power generation industry, rotary drives are generally equipped with DC planetary geared motors or AC geared motors are mainly used; in construction machinery, hydraulic motors are mainly used as power drive systems.



SDE Slewing Drive Performance Parameters



Model Ratio Rated Output Torque(N.m) Tilting Torque (N.m) Holding Torque (N.m) Axial Load (kN) Radial Load (kN) Efficiency Precision (°) Self-locking Weight (kg)
3" 31:1 600 1500 5800 10 15 40% ≤0.1 Yes 25
5" 37:1 800 6000 9200 16 27 40% ≤0.1 Yes 34
7" 57:1 2000 7500 13200 34 58 40% ≤0.1 Yes 56
9" 61:1 4300 16000 27200 60 130 40% ≤0.1 Yes 92
12" 78:1 5800 25000 40560 77 190 40% ≤0.1 Yes 160
14" 85:1 6750 48000 44200 110 230 40% ≤0.1 Yes 224
17" 102:1 9460 67000 53040 142 390 40% ≤0.1 Yes 320
21" 125:1 16000 89000 65000 337 640 40% ≤0.1 Yes 492
25" 150:1 21450 112000 89000 476 950 40% ≤0.1 Yes 705



Quality Control



Raw material inspection test: portable sclerometer

Surface: Thickness Gauge

Electrical performance: motor torsion tester

Anti-errosion: salt spray test machine

Anti-aging: UV test machine

Thermal adapdation: high low temperature chamber

Other jigs & fixtures toolings
