SE9 Inch Hydraulic Slewing Bearing Drive With Servo Motors For Cranes

SE9 Inch Hydraulic Slewing Bearing Drive With Servo Motors For Cranes

  • SE9 Inch Hydraulic Slewing Bearing Drive With Servo Motors For Cranes
  • SE9 Inch Hydraulic Slewing Bearing Drive With Servo Motors For Cranes
SE9 Inch Hydraulic Slewing Bearing Drive With Servo Motors For Cranes
Product Details:
Place of Origin: China
Brand Name: HangTuo
Certification: CE, ISO9001
Model Number: SE9"
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 280~504 / pc
Packaging Details: plywood box
Delivery Time: 15~45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Model: 9 Inch Gear Ratio: 61:1
Efficiency: 40% Type: Horizontal Series
Application: Cranes And Liftings OEM Service: Available
Place Of Origin: Changzhou, China Driver: Servo Motors
High Light:

Hydraulic Slewing Bearing Drive

,

Hydraulic Slew Drive For Cranes

,

Hydraulic Slew Drive With Servo Motors

SE9 Inch Slewing Bearing Drive With Servo Motors For Cranes And Liftings



Slewing Bearing Drive Description



Cranes are equipment that lifts or moves heavy objects horizontally, and are widely used in various fields such as manufacturing, engineering, and transportation. Therefore, the types of cranes are also diversified due to the application in different industries, for example, there are single and double girder overhead cranes, suspended overhead cranes, gantry cranes, portal cranes, stationary cranes, tower cranes , jib crane, etc. Additionally, lifting weights range from 1.25kg to 1,000t. However, no matter what kind of crane it is, there is always the fact that where there is rotation, there are slewing bearings.



Parameters of SE Slewing Drive



SE Model Performance Parameters
Model Ratio Rated Output Torque Tilting Torque Holding Torque Axial Load Radial Load Efficiency Precision Self-locking Weight
N.m N.m N.m kN kN degree Yes kg
1" 31:1 400 1000 1800 22 12 40% ≤0.1 Yes 6
3" 31:1 300 1500 7000 30 15 40% ≤0.1 Yes 9
5" 37:1 637.5 6000 9200 68 27 40% ≤0.1 Yes 14
7" 57:1 1750 10500 13200 132 58 40% ≤0.1 Yes 23
9" 61:1 4300 49900 30800 340 130 40% ≤0.1 Yes 44
12" 78:1 5600 54400 40560 480 190 40% ≤0.1 Yes 51
14" 85:1 6750 135000 44200 680 230 40% ≤0.1 Yes 62
17" 102:1 9460 203000 53040 980 390 40% ≤0.1 Yes 85
21" 125:1 16000 271000 65000 1600 640 40% ≤0.1 Yes 141
25" 150:1 21450 346000 89000 2400 950 40% ≤0.1 Yes 182



About Us



Changzhou hangtuo uses a double-envelope technology to produce a slewing drive with ring-wound worm technology as the most important means to maximize load and improve transmission efficiency and accuracy. When the worm is engaged with the slewing bearing, multi-tooth engagement can be achieved, and when the worm is engaged, only one-tooth engagement can be achieved. The increased tooth surface engagement of the 5 to 11 teeth thus greatly enhances the strength and power of the transmission. Our range of slew drive is available in several series and covers a wide range of models. The performance range and installation dimensions can meet the needs of different applications. At present, our products can be divided into 9 basic models, the diameter of the raceway ranges from 75mm to 800mm. The load range is from 6kNm to 220kNm, the torque output is from 200Nm to 63kNm, the turning torque is from 500Nm to 271kNm, and the transmission reduction ratio is from 30:1 to 156600:1. The installation method can be horizontal, vertical or multi-axis.



We produce many different types of slew drives and offer many types of slew drives and drive components. Our slew drives can be self-locking or back-drive. The self-locking slew drive does not reverse when the reverse force is transmitted from the slewing ring to the worm, and there is no need to install a separate brake. Instead of self-locking, it can be driven in reverse. For hydraulic applications, we supply hydraulic motors to our customers. For electric equipment, we can supply gearboxes and various motors for our customers.
