High Torque 31 To 150 Gear Ratio Hydraulic Slew Drive With Hydraulic Motor For Construction Machinery

High Torque 31 To 150 Gear Ratio Hydraulic Slew Drive With Hydraulic Motor For Construction Machinery

  • High Torque 31 To 150 Gear Ratio Hydraulic Slew Drive With Hydraulic Motor For Construction Machinery
High Torque 31 To 150 Gear Ratio Hydraulic Slew Drive With Hydraulic Motor For Construction Machinery
Product Details:
Place of Origin: China
Brand Name: HangTuo
Certification: CE, ISO9001
Model Number: SE
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 280~504 / pc
Packaging Details: plywood box
Delivery Time: 15~45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Gear Ratio: 31~150 Efficiency: 40%
Type: Horizontally Installed Application: Construction Machinery
OEM Service: Available Driver: Hydraulic Motor
IP Grade: IP66 Color: As Requested
High Light:

hydraulic slew motor

,

solar tracker drive

Description



SE slew drive is an ideal driving component for truck crane, crawler crane, ship crane and excavator, and other wheeling equipment. The structure is quite compact, especially suits those space-critical equipment.



There is a wide variety of slew drive hydraulic options are available to you, such as clock, radio, and torque. You can also choose from home, industrial, and commercial. As well as from normal sizes, big sizes or small sizes.



SE Performance Data



Model Ratio Rated Output Torque Tilting Torque Holding Torque Axial Load Radial Load Efficiency Precision Self-locking Weight
N.m N.m N.m kN kN degree Yes kg
1" 31:1 400 1000 1800 22 12 40% ≤0.1 Yes 6
3" 31:1 300 1500 7000 30 15 40% ≤0.1 Yes 9
5" 37:1 637.5 6000 9200 68 27 40% ≤0.1 Yes 14
7" 57:1 1750 10500 13200 132 58 40% ≤0.1 Yes 23
9" 61:1 4300 49900 30800 340 130 40% ≤0.1 Yes 44
12" 78:1 5600 54400 40560 480 190 40% ≤0.1 Yes 51
14" 85:1 6750 135000 44200 680 230 40% ≤0.1 Yes 62
17" 102:1 9460 203000 53040 980 390 40% ≤0.1 Yes 85
21" 125:1 16000 271000 65000 1600 640 40% ≤0.1 Yes 141
25" 150:1 21450 346000 89000 2400 950 40% ≤0.1 Yes 182



Recommended slewing drive



Enclosed housing slewing drive SE1 SE3 SE5 SE7 SE9 SE12 SE14 SE21
Precise enclosed housing slewing drive ZE3 ZE5 ZE7 ZE9
Worm gear slewing drive WE1 WE3 WE5 WE7 WE9
Dual axis slewing drives SDE3 ZDE3 SDE5 ZDE5 SDE7 ZDE7
Vertical enclosed slewing Drive VE3 VE5 VE6 VE7 VE9 VE12


Applications



solar trackers, wind turbines, satellite and radar dishes, truck cranes, man lifts, utility equipment, hydraulic equipment attachments, oil tool equipment, tire handlers, digger s, and automotive lifts.
