Providing Innovative and Cost-effective Slewing Drives
 |
| Place of Origin: | Changzhou |
| Brand Name: | HT |
| Certification: | CE, ISO9001 |
| Model Number: | VE |
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | Plywood |
| Delivery Time: | 7～15 days |
| Payment Terms: | T/T |
| Operating Temperature: | -40°C To +120°C | Installation Site: | Solar Power Plant, Roof, Farm… |
|---|---|---|---|
| Rotation Range: | 360° Continuous Or As Requested | Worm Feature: | Double Enveloping Worm |
| Structure: | Worm And Gear | Feature: | Long Life And Self Locking |
| Colour: | Orange, Gray Or As Requested | Grease Type: | Mobil EP-2 |
| High Light: | Gray Worm Gear Slewing Drive,Double Enveloping Worm Gear Slewing Drive,Long Lifespan Worm Gear Slewing Drive |
||
Our Solar Slew Drive uses a planetary gearbox power source, providing smooth and efficient movement for your solar panels. With our east-west tracking slewing drive, you can easily adjust the position of your solar panels to ensure maximum exposure to the sun, increasing the efficiency of your solar power system and giving you more power for your money.
The Solar Slew Drive is designed with easy maintenance in mind. Simply add grease regularly to ensure smooth operation and extended lifespan. With proper maintenance, our Solar Slew Drive can withstand a wide range of temperatures, from -40°C to +120°C. This means that you can rely on our product to perform even in the harshest of conditions.
Whether you're looking for a solar panel slewing drive for a small rooftop installation or a large solar power plant, our Solar Slew Drive has you covered. With its high-precision movement and durable construction, you can rely on our product to provide years of reliable service. So why wait? Invest in our Solar Slew Drive today and start enjoying the benefits of efficient solar power.
| Model | Ratio | Rated Output Torque (N.m) | Tilting Torque (N.m) | Holding Torque (N.m) | Axial Load (kN) | Radial Load (kN) | Efficiency | Precision (°) | Self-locking | Weight (kg) |
| 3" | 31:1 | 600 | 1500 | 1800 | 22 | 15 | 40% | ≤0.1 | Yes | 12 |
| 5" | 37:1 | 800 | 5000 | 9200 | 16 | 27 | 40% | ≤0.1 | Yes | 18 |
| 7" | 57:1 | 1750 | 7000 | 13200 | 34 | 58 | 40% | ≤0.1 | Yes | 32 |
| 8" | 51:1 | 2250 | 11200 | 20400 | 50 | 80 | 40% | ≤0.1 | Yes | 28 |
| 9" | 61:1 | 2250 | 16000 | 30800 | 60 | 130 | 40% | ≤0.1 | Yes | 52 |
| 12" | 78:1 | 4300 | 25000 | 40560 | 77 | 190 | 40% | ≤0.1 | Yes | 65 |
| 14" | 85:1 | 5600 | 48000 | 44200 | 110 | 230 | 40% | ≤0.1 | Yes | 88 |
| 17" | 102:1 | 6750 | 67000 | 53040 | 142 | 390 | 40% | ≤0.1 | Yes | 135 |
| 21" | 125:1 | 16000 | 89000 | 65000 | 337 | 640 | 40% | ≤0.1 | Yes | 192 |
| 25" | 150:1 | 21450 | 112000 | 89000 | 476 | 950 | 40% | ≤0.1 | Yes | 251 |
| Technical Parameter | Description |
|---|---|
| Type Of Tooth | Helical Tooth |
| Grease Type | Mobil EP-2 |
| Colour | Orange, Gray Or As Requested |
| Rotation Range | 360° Continuous Or As Requested |
| Mounting Options | Horizontal, Vertical Or Custom |
| Product Surface | Anti-rust Plastic Powder |
| Brake | Not Needed |
| Slew Drive Deceleration | Two-stage |
| Power Source | Planetary Gearbox |
| Worm Feature | Double Enveloping Worm |
This Solar Slew Drive is designed for PV trackers, azimuth and elevation tracking slewing drive to change fixed solar panel system to movable.
The HT Solar Slew Drive is highly versatile and can be used in a variety of applications. It is suitable for use in solar power plants, rooftops, farms, and other installations. The device's 360° continuous rotation range provides unparalleled flexibility, making it ideal for applications that require precise positioning and movement.
The HT Solar Slew Drive is made from QT700 material, which is known for its strength and durability. This material is resistant to wear and tear, and it can withstand harsh environmental conditions. The device is available in a range of mounting options, including horizontal, vertical, or custom configurations.
The HT Solar Slew Drive is easy to install and comes with a limited warranty of 3~10 years, depending on the specific model. It is packaged in plywood for safe transportation and can be delivered within 7 to 15 days. Payment terms are T/T, and the minimum order quantity is 1 unit.
If you are looking for a reliable and durable solar slew drive, the HT Solar Slew Drive is an excellent choice. Its versatility, strength, and durability make it the ideal solution for a wide range of applications. Contact us today to learn more about this exceptional product.
The Solar Slew Drive product technical support and services include:
Our team of technical experts is available to assist you with any questions or issues you may have with your Solar Slew Drive product.
