24V Solar Slew Drive For Single Solar Tracking System 9 Inches

24V Solar Slew Drive For Single Solar Tracking System 9 Inches

  • 24V Solar Slew Drive For Single Solar Tracking System 9 Inches
  • 24V Solar Slew Drive For Single Solar Tracking System 9 Inches
24V Solar Slew Drive For Single Solar Tracking System 9 Inches
Product Details:
Place of Origin: China
Brand Name: HangTuo
Certification: CE, ISO9001
Model Number: VE9
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 280~504 / pc
Packaging Details: plywood box
Delivery Time: 15~45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Model: 9 Inches Gear Ratio: 61:1
Application: Single Solar Tracking System Place Of Origin: Changzhou, China
Driver: 24V DC Motor Installation: Vertical
Color: As Requested Backlash: <0.01 °
High Light:

Single Solar Tracking System Slew Drive

,

24V Solar Slew Drive

,

Solar Tracking System Slew Drive 9Inches

24V Solar Slew Drive For Single Solar Tracking System



24V Solar Slew Drive Description



Slewing drive with 24V DC motor is a compact design applied in solar industry. It can be also applied in consturction machinery like mobile applications, including man lifts, lifting cranes, and other areas such as satellite/antenna, robot, etc. We offer an extensive range of slewing drives to meet customers’ specifications and needs and deliver on safety, reliability and availability.

24V Solar Slew Drive For Single Solar Tracking System 9 Inches 0



Parameters of VE Slewing Drives



Model Ratio Rated Output Torque Tilting Torque Axial Load Radial Load Holding Torque Efficiency Precision Self-locking Weight
N.m N.m kN kN N.m degree Yes kg
3" 31:1 300 1500 3.6 15 7000 40% ≤0.1 Yes 13kg
5" 37:1 637.5 5000 16 27 9200 40% ≤0.1 Yes 18kg
7" 57:1 1750 7000 34 58 13200 40% ≤0.1 Yes 28kg
8" 51:1 2250 11200 50 80 20400 40% ≤0.1 Yes 35kg
9" 61:1 4300 16000 60 130 27200 40% ≤0.1 Yes 51kg
12" 78:1 5600 25000 77 190 40560 40% ≤0.1 Yes 61kg
14" 85:1 6750 48000 110 230 44200 40% ≤0.1 Yes 78 kg
17" 102:1 9460 67000 142 390 53040 40% ≤0.1 Yes 105 kg
21" 125:1 16000 89000 337 640 65000 40% ≤0.1 Yes 185 kg
25" 150:1 21450 112000 476 950 89000 40% ≤0.1 Yes 244 kg




Advantages



1. Rotation 360 degrees

2. Connection of a driving motor from the left or right side,

3. During installation, it is not necessary to adjust the gearing clearance; this is already set by the producer before factory

4. Simple installation and low maintenance

5. Rational space utilization

6. The gear is self-locking; therefore a brake is not necessary

7. Easy and fluent method of starting and stopping

8. High accuracy
