VE9 Vertical Installed Solar Slewing Ring Drive With Square Tube For Sun Tracking System

VE9 Vertical Installed Solar Slewing Ring Drive With Square Tube For Sun Tracking System

  • VE9 Vertical Installed Solar Slewing Ring Drive With Square Tube For Sun Tracking System
  • VE9 Vertical Installed Solar Slewing Ring Drive With Square Tube For Sun Tracking System
VE9 Vertical Installed Solar Slewing Ring Drive With Square Tube For Sun Tracking System
Product Details:
Place of Origin: China
Brand Name: HangTuo
Certification: CE, ISO9001
Model Number: VE9"
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 280~380/ pc
Packaging Details: plywood box
Delivery Time: 15~45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Material: QT Model: VE9 Inches
Gear Ratio: 61:1 Rated Output Torque: 6100 Nm
Holding Torque: 36000 Nm Tilting Torque: 16300 Nm
Efficiency: 40% Standard Color: RAL 9006
High Light:

Vertical Installed Solar Slewing Ring Drive

,

6100 Nm Solar Slewing Drive

,

Sun Tracking System Solar Slewing Drive

VE9 Vertical Installed Solar Slewing Ring Drive With Square Tube For Sun Tracking System



Slewing Ring Drive Description



Although slewing drive reducer products have the characteristics of high integration, simple structure and superior performance, rational use is still very important, and daily maintenance is also indispensable. In the case of high-speed and high-frequency running back and forth repeatedly, excessive impact will inevitably accelerate the damage of the teeth meshing parts of the transmission parts. During the operation process, pay attention to reducing the impact of the start and stop stages, especially do not savagely increase or decrease the throttle without transition. The service life of the parts has great benefits. In other low-speed, heavy-duty, and long-cycle working environments, the slewing reducer can maintain long-term stable and efficient operation by regularly replacing and filling lubricating oil according to the design requirements, and eliminating the jamming and blocking caused by foreign objects in time.



Technical Data of VE Slewing Drives



Model Ratio Rated Output Torque(N.m) Tilting Torque(N.m) Holding Torque(N.m) Axial Load(kN) Radial Load(kN) Efficiency Precision(°) Self-locking Weight(kg)
3" 31:1 600 1500 1800 22 15 40% ≤0.1 Yes 12
5" 37:1 800 5000 9200 16 27 40% ≤0.1 Yes 18
7" 57:1 1750 7000 13200 34 58 40% ≤0.1 Yes 32
8" 51:1 2250 11200 20400 50 80 40% ≤0.1 Yes 28
9" 61:1 2250 16000 30800 60 130 40% ≤0.1 Yes 52
12" 78:1 4300 25000 40560 77 190 40% ≤0.1 Yes 65
14" 85:1 5600 48000 44200 110 230 40% ≤0.1 Yes 88
17" 102:1 6750 67000 53040 142 390 40% ≤0.1 Yes 135
21" 125:1 16000 89000 65000 337 640 40% ≤0.1 Yes 192
25" 150:1 21450 112000 89000 476 950 40% ≤0.1 Yes 251



Advantages



1. High backholding torque

2. Self-locking to improve the solar tracking system's safety

2. Hard stop inside

3. Enveloping worm drive inside

4. Multi tooth contact to ensure high load and minimize backlash



Applicatons



Slewing drive bearings are usually found in application such as: wind turbines, heavy load transporters, solar trackers, harbor cranes, hydraulic equipment, crane steering mechanisms, automation systems, heavy load manipulators, yaw and pitch control tables.
