Hourglass Dual Axis Worm Gear Slewing Bearing For Parabolic CSP Solar PV Tracking

Hourglass Dual Axis Worm Gear Slewing Bearing For Parabolic CSP Solar PV Tracking

  • Hourglass Dual Axis Worm Gear Slewing Bearing For Parabolic CSP Solar PV Tracking
  • Hourglass Dual Axis Worm Gear Slewing Bearing For Parabolic CSP Solar PV Tracking
Hourglass Dual Axis Worm Gear Slewing Bearing For Parabolic CSP Solar PV Tracking
Product Details:
Place of Origin: China
Brand Name: HangTuo
Certification: CE, ISO9001
Model Number: SDE3"
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 100~1200/ pc
Packaging Details: plywood box
Delivery Time: 15~45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Material: QT Model: SDE3"
Gear Ratio: 31:1 Rated Output Torque: 600 Nm
Holding Torque: 5800 Nm Tilting Torque: 1800 Nm
Efficiency: 40% Application: PV Tracking
High Light:

Dual Axis Worm Gear Slewing Bearing

,

Hourglass Worm Gear Slewing Drive

,

Solar PV Tracking Gear Slewing Drive

Hourglass Dual Axis Worm Gear Slewing Bearing For Parabolic CSP And Solar PV Tracking


Worm Gear Slewing Bearing Description


The slewing drive device is widely used and can be used in any occasion where the rotary motion is required at the same time as the low speed is required. When the output motion of a large torque and high precision are to be realized or the body structure is compact and the integrity is required, the slewing drive device is a a perfect solution.



SDE Series Slewing Drive Performance Parameter


Model Ratio Rated Output Torque (N.m) Tilting Torque (N.m) Holding Torque (N.m) Axial Load (kN) Radial Load (kN) Efficiency Precision (°) Self-locking Weight (kg)
3" 31:1 600 1500 5800 10 15 40% ≤0.1 Yes 25
5" 37:1 800 6000 9200 16 27 40% ≤0.1 Yes 34
7" 57:1 2000 7500 13200 34 58 40% ≤0.1 Yes 56
9" 61:1 4300 16000 27200 60 130 40% ≤0.1 Yes 92
12" 78:1 5800 25000 40560 77 190 40% ≤0.1 Yes 160
14" 85:1 6750 48000 44200 110 230 40% ≤0.1 Yes 224
17" 102:1 9460 67000 53040 142 390 40% ≤0.1 Yes 320
21" 125:1 16000 89000 65000 337 640 40% ≤0.1 Yes 492
25" 150:1 21450 112000 89000 476 950 40% ≤0.1 Yes 705


About Us



We are committed to researching, developing and applying high quality, precision transmission equipment products, who provides reliable mechanical actuator for horizonal single axis, dual-axis photovoltaic tracking system, CSP, CPV solar tracking design.



Applicaitons


For wind generators: Slewing drives are used to rotate the pedestal in wind turbines

For Construction Machinery Application: widely applied on mounted truck crane, aerial working platform, cranes, timber grab
For Industry Market: Automation and CNC assembly line, robotic arm

For Satellite: space communications and global positioning systems in satellite dish
