Small Envelope Worm Gear Solar Slew Drive For Single Axis Sun Tracking System

Small Envelope Worm Gear Solar Slew Drive For Single Axis Sun Tracking System

  • Small Envelope Worm Gear Solar Slew Drive For Single Axis Sun Tracking System
  • Small Envelope Worm Gear Solar Slew Drive For Single Axis Sun Tracking System
Small Envelope Worm Gear Solar Slew Drive For Single Axis Sun Tracking System
Product Details:
Place of Origin: China
Brand Name: HangTuo
Certification: CE, ISO9001
Model Number: VE7"
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 280~504 / pc
Packaging Details: plywood box
Delivery Time: 15~45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Material: QT Model: VE7"
Holding Torque: 13200Nm Tilting Torque: 7000Nm
Rated Output Torque: 1750Nm Gear Ratio: 57:1
Efficiency: 40% Standard Color: RAL9006
High Light:

Small Envelope Worm Gear Slew Drive

,

Gear Slew Drive Sun Tracking System

,

13200 Nm Gear Slew Drive

Small Envelope Worm Gear Slew Drive For Single Axis Sun Tracking System


Envelope Worm Gear Slew Drive Description

Slewing drives can be divided into open and closed types. The slewing drives we produce are basically enclosed type, and are mostly used in applications with excessively harsh environments and short maintenance and maintenance intervals, such as solar photovoltaic tracking systems. The open type slewing drives we produce are mainly used in occasions that facilitate the inspection, maintenance and upkeep of the machine parts, and are also more convenient to replace, such as in the field of construction machinery. The open-type structure is more convenient for engineers to overhaul.

VE Type Slewing Drive Technical Data



Model Ratio Rated Output Torque Tilting Torque Axial Load Radial Load Holding Torque Efficiency Precision Self-locking Weight
N.m N.m kN kN N.m degree Yes kg
3" 31:1 300 1500 3.6 15 7000 40% ≤0.1 Yes 13kg
5" 37:1 637.5 5000 16 27 9200 40% ≤0.1 Yes 18kg
7" 57:1 1750 7000 34 58 13200 40% ≤0.1 Yes 28kg
8" 51:1 2250 11200 50 80 20400 40% ≤0.1 Yes 35kg
9" 61:1 4300 16000 60 130 27200 40% ≤0.1 Yes 51kg
12" 78:1 5600 25000 77 190 40560 40% ≤0.1 Yes 61kg
14" 85:1 6750 48000 110 230 44200 40% ≤0.1 Yes 78 kg
17" 102:1 9460 67000 142 390 53040 40% ≤0.1 Yes 105 kg
21" 125:1 16000 89000 337 640 65000 40% ≤0.1 Yes 185 kg
25" 150:1 21450 112000 476 950 89000 40% ≤0.1 Yes 244 kg


Application



Photovoltaic power generation is an important application field of slewing drive. A solar photovoltaic system that uses a slewing drive device as a rotating component can accurately adjust the horizontal and elevation angles of the system according to the different positions of the sun in a day, so that the solar panels can be output at all times. at the best receiving angle.
