VE7 Envelope Worm Gear Solar Slew Drive Gearbox For Horizontal Sun Trackers

VE7 Envelope Worm Gear Solar Slew Drive Gearbox For Horizontal Sun Trackers

  • VE7 Envelope Worm Gear Solar Slew Drive Gearbox For Horizontal Sun Trackers
  • VE7 Envelope Worm Gear Solar Slew Drive Gearbox For Horizontal Sun Trackers
VE7 Envelope Worm Gear Solar Slew Drive Gearbox For Horizontal Sun Trackers
Product Details:
Place of Origin: China
Brand Name: HangTuo
Certification: CE, ISO9001
Model Number: VE7"
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 280~504 / pc
Packaging Details: plywood box
Delivery Time: 15~45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Material: QT Model: VE7"
Gear Ratio: 57:1 Rated Output Torque: 1750 Nm
Holding Torque: 13200 Nm Tilting Torque: 7000 Nm
Efficiency: 40% Standard Color: RAL 9006
High Light:

Worm Gear Solar Slew Drive Gearbox

,

VE7 Envelope Slewing Drive

,

Horizontal Sun Trackers Slew Drive

VE7 Envelope Worm Gear Slew Drive Gearbox For Horizontal Single Axis Sun Solar Trackers



Envelope Worm Gear Slew Drive Description



A slewing drive is a directly mountable unit consisting of a gear and a worm for the simultaneous transmission of axial and radial forces and tilting moments, hydraulically or electrically driven within a completely enclosed housing.



Technical Date of Vertical Series



Model Ratio Rated Output Torque Tilting Torque Axial Load Radial Load Holding Torque Efficiency Precision Self-locking Weight
N.m N.m kN kN N.m degree Yes kg
3" 31:1 300 1500 3.6 15 7000 40% ≤0.1 Yes 13kg
5" 37:1 637.5 5000 16 27 9200 40% ≤0.1 Yes 18kg
7" 57:1 1750 7000 34 58 13200 40% ≤0.1 Yes 28kg
8" 51:1 2250 11200 50 80 20400 40% ≤0.1 Yes 35kg
9" 61:1 4300 16000 60 130 27200 40% ≤0.1 Yes 51kg
12" 78:1 5600 25000 77 190 40560 40% ≤0.1 Yes 61kg
14" 85:1 6750 48000 110 230 44200 40% ≤0.1 Yes 78 kg
17" 102:1 9460 67000 142 390 53040 40% ≤0.1 Yes 105 kg
21" 125:1 16000 89000 337 640 65000 40% ≤0.1 Yes 185 kg
25" 150:1 21450 112000 476 950 89000 40% ≤0.1 Yes 244 kg



Our Services & Strength



1.Raw material from reliable suppliers;
2.Production process is in strict accordance with ISO9001 Quality Management System .
3.Strict in-process quality control and 100% finished product inspection before delivery;
4.Third party product inspections are acceptable upon customer request.
5.Adoption of standardized product design process and APQP, PPAP, FEMA for application analysis.
6. OEM service

6.1 We provide standard products and non-standard products;

6.2 We provide customized samples, customized drawings, door-to-door mapping and other services;

6.3 We provide a full range of services, including design, processing, packaging, transportation, etc.
