Sde9 Solar Tracker Slew Drive With Encoder Precise Tracking For Antenna And Satellite

Sde9 Solar Tracker Slew Drive With Encoder Precise Tracking For Antenna And Satellite

  • Sde9 Solar Tracker Slew Drive With Encoder Precise Tracking For Antenna And Satellite
  • Sde9 Solar Tracker Slew Drive With Encoder Precise Tracking For Antenna And Satellite
Sde9 Solar Tracker Slew Drive With Encoder Precise Tracking For Antenna And Satellite
Product Details:
Place of Origin: China
Brand Name: HangTuo
Model Number: SDE
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 280~504 / pc
Packaging Details: plywood box
Delivery Time: 15~45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Certification: ISO, CE Model: SDE Slew Drives
Protect: Enclosed Place Of Origin: Changzhou, China
Material: 42CrMo Or 50Mn Warranty: 5~10 Years
Size: 3 Inch To 25 Inch Color: Customer Required
High Light:

sde9 solar tracker slew drive

,

solar tracker slew drive with encoder

,

iso solar slew drive



SDE9 Solar Tracker Slew Drive With Encoder, Precise Tracking For Antenna And Satellite



Description



The slew drives with encoders are used in Antenna or Satellite tracking which need high precise and need feedback of the rotating. The slewing dives are with 0.05° tracking precision and come with an IP66 rated protection grade, which protects the drive from outdoor harsh environmental conditions as well as dirt, sand, dust and even water. The drive is designed in such a way that huge loads can be carried with compact form while insure the tracking presicion. The gears used in the assembly could be hardened if necessary according to customers's different applications, so that they provide maximum durability and longer life.



Sde9 Solar Tracker Slew Drive With Encoder Precise Tracking For Antenna And Satellite 0





SDE Model Performance Parameters



Model Rated Output Torque (N.m) TiltingTorque (N.m) Holding Torque (N.m) Axial Load (kN) Radial Load (kN) Ratio Efficiency Precision (degree) IP Self-locking Weight (kg)
3" 600 1500 5800 10 15 31:1 40% ≤0.10 66 Yes 25kg
5" 800 6000 9200 16 27 37:1 40% ≤0.10 66 Yes 34kg
7" 2000 7500 13200 34 58 57:1 40% ≤0.10 66 Yes 56kg
9" 4300 16000 27200 60 130 61:1 40% ≤0.10 66 Yes 92kg
12" 5800 25000 40560 77 190 78:1 40% ≤0.10 66 Yes 160 kg
14" 6750 48000 44200 110 230 85:1 40% ≤0.10 66 Yes 224kg
17" 9460 67000 53040 142 390 102:1 40% ≤0.10 66 Yes 320kg
21" 16000 89000 65000 337 640 125:1 40% ≤0.10 66 Yes 492kg
25" 21450 112000 89000 476 950 150:1 40% ≤0.10 66 Yes 705 kg



ENCODER



Sde9 Solar Tracker Slew Drive With Encoder Precise Tracking For Antenna And Satellite 1

Sde9 Solar Tracker Slew Drive With Encoder Precise Tracking For Antenna And Satellite 2

Sde9 Solar Tracker Slew Drive With Encoder Precise Tracking For Antenna And Satellite 3

Sde9 Solar Tracker Slew Drive With Encoder Precise Tracking For Antenna And Satellite 4

Sde9 Solar Tracker Slew Drive With Encoder Precise Tracking For Antenna And Satellite 5
