VE9 Orange Painting High Torque Worm Gear Slew Drive For horizontal single axis solar trackers

VE9 Orange Painting High Torque Worm Gear Slew Drive For horizontal single axis solar trackers

  • VE9 Orange Painting High Torque Worm Gear Slew Drive For horizontal single axis solar trackers
  • VE9 Orange Painting High Torque Worm Gear Slew Drive For horizontal single axis solar trackers
VE9 Orange Painting High Torque Worm Gear Slew Drive For horizontal single axis solar trackers
Product Details:
Place of Origin: China
Brand Name: HangTuo
Certification: CE, ISO9001
Model Number: VE9
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 100~1100/ pc
Packaging Details: plywood box
Delivery Time: 15~45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Place Of Origin: Changzhou, China (Mainland) Type: VE9 Slewing Drive
Material: 42CrMo Or 50Mn Warranty: 5~10 Years
Size: 3 Inch To 25 Inch Application: Flat Single Trackers
Color: Customer Required Protection: IP66
High Light:

slewing drive for solar tracking system

,

solar tracker drive

Ve9 Spray Painting High Torque Worm Gear Slew Drive Suitable For Low Latitude Areas​



Description



Slew drive, a kind of integrated drive power source of fully rotary deceleration transmission mechanism, it takes the slewing bearing as the transmission actuator and the mechanism attachment, by attaching the active part, the driving source and the shell to one ring in the inner and outer ring of the slewing bearing, while the other ring as both the transmission actuator and the connecting base of the driven working parts. In this way, by using the the characteristics of slewing bearing as the fully rotary connector to configure the drive power and the main drive parts effectively, making it a set of rotary, deceleration and drive functions and at the same time with simple structure, general type of deceleration transmission mechanism of easy manufacturing and maintenance.



VE9 Orange Painting High Torque Worm Gear Slew Drive For horizontal single axis solar trackers 0



Dimensions & Technical Data



VE9 Orange Painting High Torque Worm Gear Slew Drive For horizontal single axis solar trackers 1



Motor



Brushless DC Motor



A brushless DC motor is essentially flipped inside out, eliminating the need for brushes to flip the electromagnetic field. In brushless DC motors, the permanent magnets are on the rotor, and the electromagnets are on the stator. A computer then charges the electromagnets in the stator to rotate the rotor a full 360-degrees.



Specification:

Voltage: 24VDC

No load current: 0.6A (max)

No load output speed: 3.2 rpm

No load speed: 1300 rpm



Rated Speed: 2 rpm

Rated Torque: 43 Nm

Max Torque: 48 Nm

Rated Current: 1.8A (max)



IP Grade: IP65/66



Electrical connection:



1. Thick Red: Motor +

2. Thick Black: Motor -

3. Yellow Green: GND

4. Thin Yellow: hall B

5. Thin Red: hall +5V

6. Thin Black: hall GND

7. Thin Green: hall A



Q&A



1. How can i choose?

Please specify the wheel diameter size, width, voltage, power and no-load speed of the required motors.

2. Could I take samples to test quality and market in advance?

Sure, welcome to take samples to test our quality and service.



3. What's the total cost for samples?

Total sample cost= sample cost + freight

We will give you the best shipping cost after you choose the suitable gear motors



4. How do you ship samples?

Considering sample quantity is not big, we support ship samples by EMS, TNT or Fedex

5. What's your minimum order quantity?

10 sets after samples confirmed

6. What's your delivery time?

For standard samples: within 7days; for batch orders: within 25days.



Dimensions

VE9 Orange Painting High Torque Worm Gear Slew Drive For horizontal single axis solar trackers 2
