Providing Innovative and Cost-effective Slewing Drives
 |
| Place of Origin: | Changzhou |
| Brand Name: | HT |
| Certification: | CE, ISO9001 |
| Model Number: | VE |
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | Plywood |
| Delivery Time: | 7～15 days |
| Payment Terms: | T/T |
| Worm Feature: | Double Enveloping Worm | Product Surface: | Anti-rust Plastic Powder |
|---|---|---|---|
| Type Of Tooth: | Helical Tooth | Feature: | Long Life And Self Locking |
| Limited Warranty: | 3~10 Years | Field Life: | 30 Years |
| Self-Locking: | Yes | Structure: | Worm And Gear |
| High Light: | slewing drive solar,Corrosion Resistant worm gearbox,Long Service Life worm gearbox |
||
Maintenance: The Solar Slew Drive requires regular maintenance to ensure optimal performance. Users will need to add grease regularly to keep the drive lubricated and functioning properly.
Self-Locking: One of the key benefits of the Solar Slew Drive is its self-locking feature, which helps prevent backdriving and provides greater stability for solar panels. This feature ensures that the panels stay in place, even during harsh weather conditions.
Colour: The Solar Slew Drive is available in orange, gray, or as requested by the customer, making it easy to integrate into any solar power system design.
Protection: The Solar Slew Drive is designed to withstand harsh environmental conditions, with an IP66 rating and an enclosed construction that provides protection against dust, water, and other elements.
Installation Site: The Solar Slew Drive is designed to be used in solar power plants, roofs, farms, and other installations that require east-west tracking slewing drives. Its compact design and rugged construction make it ideal for use in challenging environments.
Conclusion:
The Solar Slew Drive is an essential component for any solar tracking system. Its self-locking feature, compact design, and rugged construction make it an ideal choice for installations that require azimuth and elevation tracking slewing drives. With regular maintenance and proper care, the Solar Slew Drive can help ensure optimal performance and reliability for solar power systems.
| Model | Ratio | Rated Output Torque (N.m) | Tilting Torque (N.m) | Holding Torque (N.m) | Axial Load (kN) | Radial Load (kN) | Efficiency | Precision (°) | Self-locking | Weight (kg) |
| 3" | 31:1 | 600 | 1500 | 1800 | 22 | 15 | 40% | ≤0.1 | Yes | 12 |
| 5" | 37:1 | 800 | 5000 | 9200 | 16 | 27 | 40% | ≤0.1 | Yes | 18 |
| 7" | 57:1 | 1750 | 7000 | 13200 | 34 | 58 | 40% | ≤0.1 | Yes | 32 |
| 8" | 51:1 | 2250 | 11200 | 20400 | 50 | 80 | 40% | ≤0.1 | Yes | 28 |
| 9" | 61:1 | 2250 | 16000 | 30800 | 60 | 130 | 40% | ≤0.1 | Yes | 52 |
| 12" | 78:1 | 4300 | 25000 | 40560 | 77 | 190 | 40% | ≤0.1 | Yes | 65 |
| 14" | 85:1 | 5600 | 48000 | 44200 | 110 | 230 | 40% | ≤0.1 | Yes | 88 |
| 17" | 102:1 | 6750 | 67000 | 53040 | 142 | 390 | 40% | ≤0.1 | Yes | 135 |
| 21" | 125:1 | 16000 | 89000 | 65000 | 337 | 640 | 40% | ≤0.1 | Yes | 192 |
| 25" | 150:1 | 21450 | 112000 | 89000 | 476 | 950 | 40% | ≤0.1 | Yes | 251 |
| Technical Parameter | Description |
|---|---|
| Product Surface | Anti-rust Plastic Powder |
| Power Source | Planetary Gearbox |
| Worm Feature | Double Enveloping Worm |
| Feature | Long Life And Self Locking |
| Maintenance | Add Grease Regularly |
| Grease Type | Mobil EP-2 |
| Structure | Worm And Gear |
| Mounting Options | Horizontal, Vertical Or Custom |
| Limited Warranty | 3~10 Years |
| Slew Drive Material | QT700 |
This Solar Slew Drive product is designed to change fixed solar panel systems to movable ones with a solar tracking system. It has a 30-year field life and is made of QT700 material.
The Solar Slew Drive is a worm and gear structure with helical tooth type, and it has grease type Mobil EP-2. It comes with a minimum order quantity of 1 and is packaged in plywood. The delivery time for the product ranges from 7 to 15 days, and the payment terms are T/T.
The Solar Slew Drive is versatile and can be used for different scenarios. It is perfect for south to north moving slewing drive, which is a crucial component of PV trackers. The Solar Slew Drive can be used in both horizontal and vertical mounting options, or customized to suit individual requirements.
With a limited warranty of 3 to 10 years, the Solar Slew Drive is a reliable and durable product that meets the demands of harsh outdoor environments. It is the ideal solution for solar energy applications that require precise and smooth movement of PV trackers, enabling them to track the sun's movement accurately.
Our Solar Slew Drive product's technical support and services include:
