7 Inch High Torque Hydraulic Drived Gearbox With IP66 Enclosed Housing For Machines

7 Inch High Torque Hydraulic Drived Gearbox With IP66 Enclosed Housing For Machines

    • 7 Inch High Torque Hydraulic Drived Gearbox With IP66 Enclosed Housing For Machines
    • 7 Inch High Torque Hydraulic Drived Gearbox With IP66 Enclosed Housing For Machines
  • 7 Inch High Torque Hydraulic Drived Gearbox With IP66 Enclosed Housing For Machines

    Product Details:

    Place of Origin: China
    Brand Name: HangTuo
    Certification: CE, ISO9001
    Model Number: SE7

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: USD 100~1200 / pc
    Packaging Details: plywood box
    Delivery Time: 15~45 days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 2000 pcs per month
    Contact Now
    Detailed Product Description
    Model: 7 Inch Gear Ratio: 57:1
    Application: Aerial Truck Place Of Origin: Changzhou, China
    Driver: Hydraulic Motor Installation: Hotizontal
    Color: As Requested Backlash: <0.1°
    High Light:

    hydraulic slew motor

    ,

    solar tracker drive



    7 Inch High Torque Hydraulic Drived Gearbox With IP66 Enclosed Housing For Machines



    Description



    Slewing ring bearings are used in rotating and turntable applications.



    Hangtuo's slewing ring bearing employs double envelop worm and gear design that provides a high precision, high torque. The bearing and gears are assembled into a self-locking, and ready-to-install housing optimized for system performance.



    Features



    1. cost-efficient workhorse in the industry

    2. used for rotation under extreme loads and conditions

    3. compact with a high power density

    4. have a housing that encloses the system to provides protection from harsh environment

    5. allow for simple integration and installation into any system

    6. can be customized

    7. self-locking to increase the safety



    SE Hydraulic Slewing Drive Performance Parameters



    Model Ratio Rated Output Torque(N.m) Tilting Torque(N.m) Holding Torque(N.m) Axial Load(kN) Radial Load(kN) Efficiency Precision(°) Self-locking Weight(kg)
    1” 32:1 400 1000 1800 22 12 40% ≤0.1 Yes 6
    3” 31:1 600 1500 3000 30 16 40% ≤0.1 Yes 8
    5” 37:1 800 6000 9200 68 27 40% ≤0.1 Yes 12
    7” 57:1 2000 13500 13200 132 58 40% ≤0.1 Yes 21
    9” 61:1 4400 45000 30800 340 130 40% ≤0.1 Yes 49
    12” 78:1 5800 54400 40560 480 190 40% ≤0.1 Yes 61
    14” 85:1 6550 68000 54200 680 230 40% ≤0.1 Yes 63
    17” 102:1 9400 135600 65040 980 390 40% ≤0.1 Yes 105
    21” 125:1 16000 203400 81000 1600 640 40% ≤0.1 Yes 149
    25” 150:1 21000 271160 89000 2400 950 40% ≤0.1 Yes 204



    SE7 Slewing Drive Sheet



    Model Number SE7
    Brand Name Hangtuo
    Gear Ratio 57:1
    Output Torque (Nm) 2000
    Tilting Torque (Nm) 13500
    Holding Torque (Nm) 13200
    Weight (kgs) 21
    Working Temperature (℃) -30~+120
    Place Of Origin Changshu, China (Mainland)
    Inspect Full inspection
    Processing Forging/machining/coating/assembly
    Service 24 hours online



    Application



    slewing ring bearings are ready-to-install rotary joints for wind turbines, heavy load transporters, solar trackers, harbor cranes, hydraulic equipment, crane steering mechanisms, automation systems, heavy load manipulators, yaw and pitch control tables.



    Delivery and Package



    Minimum order quantity: 1 piece

    Payment Terms: L/C, D/A, D/P, T/T, Western Union

    Lead time 7-40 days



    Transport:

    1. by sea, shipping Port: China seaport ningbo/shanghai,

    2. by air

    3. by express, TNT, FEDEX, DHL.



    Packaging:

    Wooden case free from fumigation
