CE Certified SE Single Axis Worm Gear Slew Drive With Enclosed Housing For Solar Trackers

CE Certified SE Single Axis Worm Gear Slew Drive With Enclosed Housing For Solar Trackers

  • CE Certified SE Single Axis Worm Gear Slew Drive With Enclosed Housing For Solar Trackers
  • CE Certified SE Single Axis Worm Gear Slew Drive With Enclosed Housing For Solar Trackers
CE Certified SE Single Axis Worm Gear Slew Drive With Enclosed Housing For Solar Trackers
Product Details:
Place of Origin: China
Brand Name: HangTuo
Certification: CE, ISO9001
Model Number: SE
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 280~504 / pc
Packaging Details: plywood box
Delivery Time: 15~45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Type: Enclosed Material: 42CRMN Or 50Mn
Color: As Requested Effciency: 40%
Model: SE Single Axis Ratio: 30:1-125:1
IP Grade: IP66 Application: Solar Trackers
High Light:

worm gear slewing ring

,

worm gear motor



CE Certified SE Single Axis Worm Gear Slew Drive With Enclosed Housing For Solar Trackers



Description



Slew drive is a new kind of slew products, easy to mount and save more space.
Slew drive consists of worm, slew ring, hosing, motor and so on. The core part is slewing bearing, so slew drive can also bear axial, radial loading and titling moment at the same time.



CE Certified SE Single Axis Worm Gear Slew Drive With Enclosed Housing For Solar Trackers 0



Advantages


1. Compact design and space saving installation.
2. Modular construction allows very quick modifications.
3. Maximum load capacity.
4. Easy to integrate into existing applications.
5. Long life.
6. Almost free of maintenance.
7. Special designs available.



Performance Parameters of SE Series



Model Ratio Rated Output Torque Tilting Torque Holding Torque Axial Load Radial Load Efficiency Precision Self-locking Weight
N.m N.m N.m kN kN degree Yes kg
1" 31:1 400 1000 1800 22 12 40% ≤0.1 Yes 6
3" 31:1 300 1500 7000 30 15 40% ≤0.1 Yes 9
5" 37:1 637.5 6000 9200 68 27 40% ≤0.1 Yes 14
7" 57:1 1750 10500 13200 132 58 40% ≤0.1 Yes 23
9" 61:1 4300 49900 30800 340 130 40% ≤0.1 Yes 44
12" 78:1 5600 54400 40560 480 190 40% ≤0.1 Yes 51
14" 85:1 6750 135000 44200 680 230 40% ≤0.1 Yes 62
17" 102:1 9460 203000 53040 980 390 40% ≤0.1 Yes 85
21" 125:1 16000 271000 65000 1600 640 40% ≤0.1 Yes 141
25" 150:1 21450 346000 89000 2400 950 40% ≤0.1 Yes 182
