14 Inch Withstand Heavy Load Slewing Ring Drive With Hydraulic Motors For Truck Mounted Cranes

14 Inch Withstand Heavy Load Slewing Ring Drive With Hydraulic Motors For Truck Mounted Cranes

  • 14 Inch Withstand Heavy Load Slewing Ring Drive With Hydraulic Motors For Truck Mounted Cranes
14 Inch Withstand Heavy Load Slewing Ring Drive With Hydraulic Motors For Truck Mounted Cranes
Product Details:
Place of Origin: China
Brand Name: HangTuo
Certification: CE, ISO9001
Model Number: SE14
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 280~504 / pc
Packaging Details: plywood box
Delivery Time: 15~45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 pcs per month
Contact Now
Detailed Product Description
Gear Ratio: 85:1 Type: Enclosed
Application: Construction Machinery OEM Service: Available
Driver: Hydraulic Motor IP Grade: IP66
Color: As Requested Accuracy: Less Than 0.01 Degree
High Light:

hydraulic slew motor

,

solar tracker drive

Description



Slew drive is a new kind of slew products. It is composed of worm, slewing ring, total enclosed housing, electric or hydraulic motor. The core parts is slewing ring, so it can bear axial loading, radial loading and titling moment at the same time. Compare with the traditional slew products, slew drive is easy to install and maintain, it can also save more space. The typical applications of our slew drive include agriculture machinery, construction machinery, conveyor systems, cranes, drilling rigs, mining, military, dredges, amusement park, solar generation system and other new energy field.



Application



Our product can be widely used in heavy-duty flat-panel trucks, container cranes, Truck cranes, aerial vehicles, solar power generation systems, engineering machine, new energy and other heavy-load areas.



SE Performance Data



Model Ratio Rated Output Torque Tilting Torque Holding Torque Axial Load Radial Load Efficiency Precision Self-locking Weight
N.m N.m N.m kN kN degree Yes kg
9" 61:1 4300 49900 30800 340 130 40% ≤0.1 Yes 44
12" 78:1 5600 54400 40560 480 190 40% ≤0.1 Yes 51
14" 85:1 6750 135000 44200 680 230 40% ≤0.1 Yes 62
17" 102:1 9460 203000 53040 980 390 40% ≤0.1 Yes 85
21" 125:1 16000 271000 65000 1600 640 40% ≤0.1 Yes 141
25" 150:1 21450 346000 89000 2400 950 40% ≤0.1 Yes 182



Optional Information



- Payment : T/T, L/C

- Delivery : Sea Freight

- Origin : China

- Minimum Order : 1

- Packaging : Anticorrosive wooden box, free of fumigation

- Samples : Charge

- Remarks : We can provides a wide range of services and products from design, research&development to manufacture and delivery. Pls ask us for detailed drawings of your interested products.
